NH/NS单缸液压圆锥破碎机
丁宝勤 13906276368(技术)
电话：0513-88400999 传真：0513-88400998 邮箱：jszk@vip.163.com
NH、NS系列的高速圆锥破碎机是专门为采石场场主或经理需要所研发的。结合实际验证的破碎概念与其它相关的专业知识，这款适用于第二和第三阶段的破碎机引进了科技原理。它所具备的高性能和可靠性，能帮助您的石场达到理想的效果。
NH、NS系列的高速圆锥破碎机体积比市场上的同规格产品的体积小，也相对较轻，却能提供高水平的破碎生产。将这款破碎机加上高品质原装零配件，他们将能满足现代化矿物破碎的苛刻要求。
NH and NS series high-speed cone crusher is developed especially for your needs as the owner or manager of drilling mineral. According to the proven crushing concepts and professional knowledge from the Swedish consultants, the series introduce the latest technological theory applicable to the crushers at stage II and 111. Focus on the high-performance and reliability you desire. the NH and NS series high-speed cone crushers can help your drilling mineral meet the expectations you are always hoping but cannot reach so far.
Although the shape of NH and NS series high-speed cone crusher is smaller and lighter than that of the similar one in the current market.it can realize the crushing production at higher level. The series of crusher plus high quality and durable original spare parts can meet the strict requirement of modern drilling and crushing.
技术参数表|Technical Date
型号 | 产量 | 进料粒度上限 | 排料口调整尺寸 | 功率(kw) | 重量 |
NH420 | 25-130 | 29-135( 11/8-51/4) | 4-35(5/35-11/4) | 90( 120) | 5300(11700) |
NH430 | 35-220 | 35-185( 11/2-71/2) | 5-41(5/16-1 1/2) | 132( 177) | 9200(20300) |
NH440 | 65-415 | 38-215( 13/8-81/2) | 8-44(1-13/4) | 220(295) | 14300(31500) |
NH660 | 145-660 | 50-275(2 1/2-103/4) | 13-35(1/2-2 ) | 315(422) | 24200(53352) |
NH870 | 280-1510 | 80-300(3.2-11.8 ) | 10-70( 0.4-2.8) | 520(697) | 50000(110200) |
NS420 | 70-170 | 200-240(8-91/2) | 19-38(3/4-1 1/2) | 90( 120) | 6800(15000) |
NS430 | 90-345 | 235-360(10-14 ) | 19-51(3/4-21/8) | 132( 177) | 12000(26400) |
NS440 | 195-600 | 300-450(12-18 ) | 25-54( 1-21/8) | 220(295) | 19300(42500) |
NS660 | 320-1050 | 500-560(20-22 ) | 38-83( 11/2-31/4) | 315(422) | 35700(78705) |
