HD型袋式除尘器

      HD型袋式除尘器有六种规格：分A、B、C三型，A型设灰门、B型设抽屉，C型既不设灰门也不带抽屉，下部加法兰根据用户要求直接配接在库顶、料仓、皮带运办机等扬尘设备上就地除尘，粉尘直接回收。
      This series bag filter has six specifications which are A,B and C types. Type A is designed dust door, Type B is designed drawer and type C is designed no dust door and drawer. Bottom flange is arranged in scattering dust equip?ment of top silo, material silo, belt conveyor according to the user7 s requirement. Power is reclaimed directly.

      结构特点：
1、风机部件采用通用标准风机，便于维修更换，并采用隔震设施，噪声??；
2、滤料选用的是“729”圆筒滤袋，过滤效果好，使用寿命长；
3、 清灭机构是采用电动机带动边杆机构，使滤袋抖动而清除滤袋内表面的方法，其控制装置分手控或自控两种，清火时间长短用时间继电器自行调节(电控箱随除尘器配套)；
4、灰门采用抽门式、灰门式两种结构，清除灰尘十分方便。

       Structure characters:
1.The part of fan is applied standard fan and is convenient to repair and change. It use shaking resistant acces?sory and small noise.
2.Filtering material is used 729 round cylinder filtering bag. It is characterized by good filtering efficiency and long life.
3.Removing dust structure is driven pole structure by motor and clean filtering bag by shaking. Control device has hand control and automatic control.The time of removing dust is adjusted by time relay. Electric control cabinet is placed an order together with dust filter.
4.Dust door is used taking out door and dust door. It is convenient to remove the dust.

      工作原理：
      随过滤时间，滤袋内表面黏附的粉尘也不断增加，滤袋阻力随之上升，从而影响除尘效果；采用自控清灰尘机构进行定时控振清灰或手控清灰机构?；笞远≌袷?，使粘在滤袋内面的粉尘抖落下来，粉尘落到灰门、抽屉或直接落到输送皮带上。

      Work principle:
      With increasing of filtering time and dust of filtering bag, the resistance of filtering bag will be risen and obtain dust efficiency. Rock and vibrate dust with automatic control dust removing structure or after manual control removing dust structure is stopped, shake for about ten seconds and make dust fall down from the surface of filtering bag. Dust fall into dust door, drawer or conveying belt etc.

      HD系列单机除尘器技术性能表
Technical capacity list of type HD series single dust filter

      使用说明
1、HD系列单机除尘器机组，安装在产生粉尘的机械设备邻近处，并由用户按照除尘机组上进风 口尺寸，自行配制金属或塑料吸尘管道和吸尘罩(亦可订货时与生产厂联系，代为配制）。
2、机组工作前应检查检修门，各法兰连接处是否密封，以免泄漏，降低除尘效果。
3、该机组电压为380V,从机组外部电线接上电源后即可开始使用，初运转时，应注意风机的 转动方向(如反转，则只需调换电源接线)。
4、机组电控箱盖，在工作时不得随意打开，如需调清灰时间，或需检修电路时，应?；蚯卸?电源后进行工作。
5、根据粉尘性质和含尘浓度的大小，调节定时清灰。
6、吸尘罩是保证机组处于理想状态的关键配件，使用单位应根据加工件的外型尺寸及粉尘的性 质，按通、近、封、便设计吸尘罩的原则，制作理想的吸尘罩。
7、本机组不适用于潮湿和带有腐蚀的气体，不应长时间处理高于12(TC的废气，如需用于处理 高温废气，请告知制造厂家订做高温滤布。
      Applied description
HD series single dust filters is installed near machine equipment which is sourcing powder. The customer should assort metal or plastic pipe and dust guard according to inlet size of dust filter. (Contact with manufacturer when placing an order.)
Check repaired door before machine is working. All flange connections should be sealing, avoid of leakage and reduce dust efficiency.
The voltage of machine is 380V.Connect with the power and start to use. When commissioning for the 1st time, note rotated direction of fan.(If it is counter-clockwise, change the wire of power.)
Not allow to open the cover of electric control case. If it need to adjust the time of dust, it must stop the machine or cut off the power.
Adjust timing dust according to powder character and dust density.
Dust guard can guarantee key component at best condition. The customer should accord to outline size of workpiece and the character of powder with through, approaching, sealing and convenient principle to design dust guard.
This machine is not used in moisture and corrosive gas. It should not handle above 120 centigrade waste gas. If it needs handle high temperature waste gas, please inform us to order high temperature filtering bag.
