BZ-Ⅰ/Ⅱ棒条闸门

        棒条闸门是根据建材、矿山、冶金等行业中对中、小固体块状物料的给料、输送、控制等工艺的要求而研制的一种阀门，适用于≤50mm物料的输送控制。

        Rod valve is used to feed, convey and control middle, small liquid powder material of workmanship require?ment according to building material, ore and metallurgical etc. industry which is a new valve. It is suitable to control and convey less than 50mm material.

结构特点：
        采用钢材焊接，结构简单、易操作、无卡阻、刚性强、不变形、使用寿命长、基本无维修量，是中、小固体块状物料控制的理想设备。
Structure features
        It is welded with excellent carbon steel. It is characterized by simple structure, easy operation, no blockage, strong rigidity, shapeless, long life and less maintenance etc. It is an ideal equipment to control middle and small powder material.

性能参数(Capacity parameter)

工作原理：
        棒条闸门一般为?？?，物料处流通状态。根据工况需要切断或调节时，需逐个插入棒条，以阻止物料流通，也可根据工况需要通过调整棒条间的间隙来控制物料的大小。

使用说明：
?  安装时两法兰间必须加密封垫片，然后均匀锁紧连接螺栓。
?  运行时不得对抽出的棒条进行猛烈撞击，以免棒条变形无法复位。
?  切断流通块料时，必须从两边依次插入棒条。
?  若长期存放，不允许露天存放或堆置。

Work principle
        Rod valve is usual op.en and material is in flow condition. Insert rod according to work condition when cutting off or adjustment. Stop material flow it. Adjust the clearance between rod quantity to control material.
Operation description:
?Add sealing gaskets between two flanges when installation. Then tight the bolt even.
When driving, not allow to impact the rod violently. In case that rod has no way to restore because of shapeless.
When cutting off flowing material, insert rod from two ends.
If it is stored for a long time, not allow to store in open air or pile.


BZ-Ⅰ外形图：                                           BZ-Ⅱ外形图：

BZ-Ⅰ/Ⅱ外形连接尺寸：
